Lifting capacity 3500 kg / 500 mm
Lifting height 2500-6500 mm
Free lift height 135-2174 mm
Mast type duplex mast or three stage full free lift
Cabin height 2150 mm
Battery 80V/300Ah or 80V/400Ah
Battery type Li-Ion (LiFePO4)
Fork length 1220-2000 mm
Clearance (center of wheelbase) 150 mm
Clearance under mast (with load) 135 mm
Overall machine width 1226 mm
Charger 80V/100A or 80V/200A
Engine type Electric
Engine power 11 kW
Net weight 4480 kg
Turning radius 2440 mm
Tire type Pneumatic or solid rubber
Travel speed with/without load 11/12 km/h
LED lights

Easy operation and excellent view: the truck adopts long tiller ratchet parking brake design for easy ope ration. Ratchet-type parking brake allows the truck stay at the slope of 15% without safety concern. Combination switch as auto motive, the seat can be adjusted back and forth so that the operator can choose the ideal driving position. U design of steering wheel, front-located multi-way valve operating device makes the operation effortless and cornfortable. Excellent design and performances: Drive system uses a horizontal fan-shaped drive axle arranged in parallel with a large transmission ratio. The battery is located at the bottom of ch assis, the truck has good stability. Drive motor uses AC maintenance-free motor. Long wheelbase (1700mm)design, better stability. 1 ntegrally forged Integrated steering axle, with shock mitigation system with excellent driving comfort and prolongs the service life. Lifting Motor located in high position so the truck can work in applications where there are water on the ground. Ergonomically designed LED display with large screen and great visibility for easy contrai and operation with ail around truck status information. Big diameter tyres with better performance for outdoor applications, and comfortable driving experience, optional to have solid tyres. Simplified structure tor easy maintenance: Simplified structure without compromising on the strength, makes the truck looks stronger. Controller assembly located on higher position for easy ventilation and maintenance. Standard lithium power, high elficiency: Fast charging with battery fully charged in 2-3 hours (Standard configuration : REMA/Anderson plugin). The intelligent high frequency charger with automobile charging technology has a working efficiency of more than 95%, which is much higher than the 80% working efficiency of traditional low frequency charger. High cost performance : the Lithium battery is more environment-friendly. There is no acid evaporation, odor and pollution during the charging process. The operation of Li-ion powered trucks are relatively quiet and zero carbon dioxide emissions. Therefore, Li-ion powered trucks is an ideal plan for the industry that has environment concern, such as food processing, chemical and pharmaceutical industry. Each lithium truck requires only one battery attributing to its fast charging feature no matter how many work shifts. The life time of lithium battery is three times that of lead acid battery. The maintenance-free feature of lithium battery gives much higher cost performance than lead-acid battery. FAST CHARGING : Charge your battery whenever and wherever you need. The unique fast-charging feature of lithium battery makes it an ideal choice for multi-shift work. Comparing with traditional lead-acid battery, it is no longer needed to change batteries among shifts, or prepare stand-by battery and special charging area for Li-ion powered trucks. Fast charging allows charging at interval from operations which extends greatly the working time of truck. ln addition, lithium battery has no memory of charging cycles which will not affect the life time at all. The lithium charger is no longer required to be placed in a specified area due to the environment-friendly feature. LITHIUM SAFETY : Efficient, Maintenance-free. Lithium battery reduces 35% energy consumption, requires no specified charging area and exempts from cost for battery maintenance. lt saves space, requires no device to be taken out of truck as well as additional ventilation and liquid filling device. The power of the lithium battery system is composed of high-safety high-density lithium iron phosphate battery, intelligent battery management system (BMS), thermal management system, and automotive-grade DC high-voltage control system. The BMS enables the communication network between the power lithium battery and controller, the truck itself, the charger and the remote management platform, real-time detection of the status of the lithium battery, the operating state of the truck and the charging state, so as to maximize the safety and reliability of lithium batteries. Options Optional different battery capacities: the standard configuration is 80V200Ah, optional 80V300Ah and 400Ah. Automotive type intelligent plug-in charging gun with high frequency charging technology. Note: press the "stop" button of the charger before pulling the gun.
